EEUFM1H471

CAP ALUM 470UF 20% 50V RADIAL TH

Original price was: $0.3500.Current price is: $0.3325.

Innovo Code#: N22003137
Brand:
Available Stock: 900

Quantity (pcs) Unit Price (USD)
1 - 99 $0.3325
100 - 999 $0.3150
1000 - 9999 $0.2975
10000 - 99999 $0.2800
Category:

Technical specifications

Mfr Panasonic Electronic Components
Series FM-A
Package Bulk
Product Status Active
Capacitance 470 µF
Tolerance ±20%
Voltage - Rated 50 V
ESR (Equivalent Series Resistance) -
Lifetime @ Temp. 5000 Hrs @ 105°C
Operating Temperature -40°C ~ 105°C
Polarization Polar
Ratings -
Applications General Purpose
Ripple Current @ Low Frequency 1.695 A @ 120 Hz
Ripple Current @ High Frequency 2.26 A @ 100 kHz
Impedance 22 mOhms
Lead Spacing 0.197" (5.00mm)
Size / Dimension 0.492" Dia (12.50mm)
Height - Seated (Max) 0.866" (22.00mm)
Surface Mount Land Size -
Mounting Type Through Hole
Package / Case Radial, Can
Base Product Number EEU-FM
